Data acquisition and monitoring
In the whole industrial field, wall-mounted industrial computer undertakes the important task of data acquisition and monitoring. It can connect multiple types of sensors at the same time, collect massive real-time data such as temperature, pressure, flow, vibration, and so on, and carry out comprehensive real-time monitoring of the operating status of the equipment without dead corners. Once the monitored data is abnormal, it can quickly trigger the alarm mechanism and automatically take corresponding corrective measures according to the preset response strategy, so as to effectively prevent the occurrence of equipment failure and avoid possible production accidents.
Specification
|
Processors
|
CPU |
Supports Intel® Skylake/KabyLake-S Core™ i3/i5/i7 /Xeon/Celeron/Pentium LGA1151 Processors |
|
Chipset |
Intel® H110/Q170/C236 |
|
|
BIOS |
AMI 32Mbit, support diskless boot, Wake-on-Network, power on/off, watchdog, etc. |
|
|
RAM |
Capacity |
4GB DDR4 2133/2400 MHz memory , Max.64GB |
|
Storage |
SATA interface SAS interface M.2 interface |
1*SATA 6*SAS (support24*SATA 3.0) 1*M.2 2280 |
|
Display |
Chipset Output |
CPU integrated graphics HD Graphics VGA+HDMI+DP single display, dual display, triple display (same/asynchronous display) 1 × VGA (maximum supported resolution: 1920 × 1080) 1 × HDMI (maximum supported resolution: 3840x2160 30HZ) 1 × DP (maximum supported resolution: 3840x2160 60HZ) |
|
Network |
chip WIFI/3G/4G |
2 × INTEL I211AT 10/100/1000M(RJ45 LAN) 1 x WIFI Module support 802.11b/g/n (M.2 PCIE half card) |
|
I/O |
USB 3.0 USB 2.0 PS/2 COM Port Audio |
4x USB3.0 4x USB2.0 1 × PS/2 keyboard and mouse 2 x COM ports (with optional VGA) 1 × LINE-OUT & MIC-IN &1x LINE IN, integrated 6-channel hi-fi audio |
|
Onboard Features |
COM Port USB2.0 USB3.0 PLT FP LED EDP SPK PCIE |
12*RS232+2*RS485 4*USB2.0 2*USB3.0 1*PLT print port 1*FP 1*SAS LED 1*EDP 1*SPK 1*PCIE3.0 X16 1*PCIE X4 4*PCIE X1 1*MINI PCIE |
|
Power Supply |
Input Rated Power Consumption |
ATX 1*24Pin +1*8Pin 200W |
|
Watchdog |
Output intervals |
Interrupt, system restart 255 Levels Timing Interval |
|
Physical Parameters |
Size |
300mm (L) x 265mm (W) x 195mm (H) |
|
Environment |
Temperature Humidity |
Operating Temperature: 0°C ~50°C Storage Temperature: -20~70°C 5%~90% Non-condensing |
|
Operating System |
Versions |
Windows 10/Windows 7 / windows8 / Linux |
Ordering Info
|
Sales Model |
Description |
|
AOS-SSH11C41S4BG |
Intel Celeron G3900 2.8GHz 4GRAM 128G SSD |
|
AOS-SSH11D41S4BG |
Intel Pentium G4400 3.3GHz 4GRAM 128G SSD |
|
AOS-SSH11I41S4BG |
Intel Core i3-6100 3.7GHz 4GRAM 128G SSD Intel Core i3-7100 3.9GHz 4GRAM 128G SSD Intel Core i3-8100 3.6GHz 4GRAM 128G SSD Intel Core i3-9100 3.6GHz 4GRAM 128G SSD |
|
AOS-SSH11F41S4BG |
Intel Core i5-6500 3.2GHz 4GRAM 128G SSD Intel Core i5-7500 3.4GHz 4GRAM 128G SSD Intel Core i5-8500 3.0GHz 4GRAM 128G SSD Intel Core i5-9500 3.0GHz 4GRAM 128G SSD |
|
AOS-SSH11J41S4BG |
Intel Core i7-6700 3.4GHz 4GRAM 128G SSD Intel Core i7-7700 3.6GHz 4GRAM 128G SSD Intel Core i7-8700 3.2GHz 4GRAM 128G SSD |
Dimension drawing
Areas of application
Suitable for education, restaurants, hotels, shopping malls, company meetings, public affairs and other areas.
