Display | J VBYONE HDMI VGA | 1 ×Vbyone Output 1 × HDMI Input+1 ×HDMI Input（Pin） 1 ×VGA Input（Pin） |
I/O | POWER ADJ DEBUG KEY LVDS
HDMI2 IN VGA USB AUDEO SPAK DP OUT USB3.0 USB-PC GPIO TP UART PC KEY AUDEO-OUT PC DET PC POWER
| 1X12PIN Power Input Interface 1X6PIN Backlight Control Interface 1X4PIN UART DEBUG Remote control key interface 1X14PIN TV Remote control key interface 2X15PIN LVDS output interface 2X2PIN Screen Power Selection Interface 2X10PIN Input Extension Interface 1X10PIN Extension Interface 1X4PIN Output Interface 1X4PIN Audio Input Interface 1X4PIN Speaker Interface 2X10PIN DP Output Interface 1XUSB3.0 1XUSB2.0 Touch Communication Interface 1X10PIN System GPIO Standby Interface 1X4PIN Touch Communication Interface 1X6PIN System/Android Remote Control Key Interface 1X4PIN System Audio Host Audio Output Interface 1X6PIN System GPIO Power-On Power-off operation detection and control 1X4PIN OPS Host independent power supply |
Power Supply | Input | On board 4pin Socket （12 ～ 19V） |
Physical Parameter | Size | Thin Mini-ITX，160x60mm |
Environment | Temperature Humid | Operation Temperature：0°C ~60°C Storage Temperature：-20~70°C 5%~90% Non-condensing |
