Motherboard features
Powerful computing and graphics processing capabilities
CPU: Support Intel Core i5/i3, Pentium and Celeron 8-9 generation low-power processors, based on advanced Coffee Lake architecture, integrated Intel UHD Graphics, support high-definition image and video processing capabilities, It can meet the needs of multimedia playback, graphical interface display and visual computing. Memory: Two SO-DIMM memory slots for DDR4 2133/2400 MHZ memory with a maximum capacity of 32GB.
IO interface rich
COM interface: provides six RS-232 serial ports, of which COM2 and COM3 are compatible with RS-485, which can be widely used in industrial bus, equipment debugging, embedded controller and other scenarios.
USB ports: Six USB ports, of which four are located in the backplane I/O, two are designed for the board pins, easy access to external devices, such as keyboard, mouse, camera and so on.
Backplane I/O ports: Includes DC power input, HDMI, USB3.0, LAN, and audio ports (MIC IN and Line-out).
Onboard I/O interface: including LVDS pin, reverse signal pin, front audio pin, USB pin and power amplifier pin, to meet the embedded system expansion needs.
Specification
|
CPU/GPU RAM Storage Sound Card Network
LVDS Dual Display COM USB Backplane I/O Onboard I/O Special function Power Heat dissipation Dimension Working Temperature Storage Temperature Ambient Humidity |
Intel Core i5/Core i3/Pentium /Celeron 8-9 GenCPU 2×SODIMM memory slots, support DDR4 2133/2400MHZ memory up to 32GB 1×SATA ,1× M.2 SSD interface Realtek ALC662, support for 5.1 channel sound 1×Realtek RTL8111H network card chip, PCI-E bus Gigabit LAN card 1×M.1 interface, support wireless network (WIFI) Dual-channel 24-bit LVDS, support for the maximum resolution: 1920 × 1200 HDMI+ LVDS synchronous, asynchronous dual display 6×COM RS-232,COM2,3 compatible with RS-485 6×USB (4 in backplane IO, 2 onboard pins) DC, HDMI, USB3.0, LAN, USB3.0, MIC IN,Line-out 1×LVDS pin, 1×invert pin, 1×USB pin, 1×front audio pin, 1×4pin amplifier pin Support Watchdog, Diskless Boot, Wake-on-Web, Power-On,Power-Off DC 19V With fan 180mm(L)×170mm(W) 0~50℃ -30~75℃ 0~90% Air Humidity, Non-Condensing |
Ordering Info
|
Sales Model |
Description |
|
AOS-MMH310I-P |
H310 |
